Today, I was watching a underwater video and suddenly asked myself if anyone has used a circular polarizer or polarizer in underwater shots or videos?

I searched on the internet but nothing conclusive.

So, my question is: What is your opinion on using a circular polarizer for underwater photography? Possible or impossible? has been done or not yet? Useful or useless?

Thanks in advance!

Nitin Kumar
  • 1,226
  • 3
  • 14
  • 24
  • 5
    Vivek has provided a great answer, but here is something else. Most of the time, to really extract the kind of detail and color fidelity you need for underwater photography, you want to use the underwater filtration. This usually means using a lot of magenta filtration to counter the strong blue tint. How much filtration you use depends on the depth, the deeper you go the more you tend to need. You can try to use just RAW and post-process WB correction, however filtration actually blocks excess blue light, usually providing better results (even if you still correct in post.) – jrista Sep 25 '12 at 18:19

3 Answers3

12

It is possible and useful - and sometimes even crucial. Look at this example of a squid: http://en.wikipedia.org/wiki/Glass_squid

It shows a picture with and without a polariser filter.

Michael Nielsen
  • 10,644
  • 35
  • 48
  • Did you know this article off the top of your head!? – Christian Chapman Sep 26 '12 at 02:40
  • 5
    I first came across it during my ph.d time where I read about 3D reconstruction in milky water, so I Knew it was used, against backscatter, like I use it on robots in damp areas, and to enhance funny creatures like jellyfish, and then I looked for a link and found the squid, which is prettier.Read more about it: http://www.opticsinfobase.org/ao/abstract.cfm?id=72169 http://webee.technion.ac.il/~yoav/publications/tWaterCVPR04.pdf – Michael Nielsen Sep 26 '12 at 06:46
8

The only source of light under water is the light that is refracted from the outside. Also there is a fact that the light that is refracted into the water surface will be partially polarized.
Partially polarized meaning that the refracted light has all planes of electromagnetic vibration other than the plane of vibration of the reflected light at the surface of water. As explained by below diagram:

enter image description here

source:wikipedia.

So from this we can understand that any light under the water will have all planes of vibration except the plane parallel to the surface of the water.

Hence using a polarizer that acts in the plane parallel to water surface will allow no light (theoretically) but a very low amount of light (practically). Using the polarizer in any other angle will result in no notable change.
From the explanation, circular polarization on underwater photography is possible. But in my opinion its more of useless. There is no real use of it in underwater photography. So it is not used for underwater.

vivek_jonam
  • 3,506
  • 7
  • 34
  • 59
  • large part of my question is still unanswered. – Nitin Kumar Aug 11 '12 at 21:25
  • @NitinKumar Do this cover your question now? – vivek_jonam Sep 02 '12 at 18:06
  • 1
    The assumption that the only light comes from above water seems flawed. I found multiple models of underwater strobes quite easily, and artificial lighting seems to be the only way to see anything deeper below. Using a polarizing filter to kill the ambient light in order to give preference to photographer's own light could be quite useful. – Imre Dec 04 '12 at 20:24
3

Can be used, but need a strong source of light - without artificial light, it is useless (see the wiki answer of glass squid higher). Also all the floating particles between you and subjects will be highly visible, so still need to be as close as possible.

karken
  • 31
  • 1
  • Based on the squish example, I'd say a polarizer actually seems to hide the particles. – Imre Dec 04 '12 at 20:38
